High Temperature Stability Fiber Optic Patch Cord With SC/UPC Connector Good Durability

  • 1
  • 2

Brand Name : OEM / BLG

Model Number : Fiber Optic Patch Pigtail Cable

Certification : CE/ ROHS / ISO

Place of Origin : China

MOQ : 500 piece

Price : Negotiable

Payment Terms : Western Union, T/T, L/C

Supply Ability : 5000pieces per week

Delivery Time : 5~10days

Packaging Details : 1pair/polybag ,250pair/carton

Connector : SC

Fiber Type : G652D or G657a1

Return Loss : > 50db

Operating Temperature : -40~70 °C

Jacket : PVC or on your require

Color : Any color is ok.

Contact Now

Supply SC / PC Fiber Optic Patch Cable Pigtail Cable With

SC / UPC Connector Fiber Optic Pigtail SC SM Simplex

Technical specifications:

Pigtail Connector PC (SM) UPC (SM) APC (SM) MM
Return Loss (dB) ≥45 ≥50 ≥60 ≥35
Insertion Loss (dB) ≤0.2 (max≤0.3)
Repeatability (dB) ≤0.1
Durability(1/Matings) ≥500
Operation Temperature (°C) -25~+70
Tensile Strength (N) ≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9
Fiber 9/125um, 50/125um,62.5/125um,ect
diameter 0.9mm 2.0mm, 3.0mm etc
Cable material PVC, LSZH
Cores Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc

Features:

---Good durability

---Good exchangeability

---High temperature stability

---Low insertion loss and back reflection loss
---Superior Quality Standard PC/UPC/APC Polishing

---Standard: Telcordia GR-326-CORE, TIA/EIA and IEC

Product packing details

Products Packing
Inner packing 1piece per plastic bag
Min order 100 pieces
100 pieces weight 2-3kg
Outer packing Carton box

Payment terms

Payment terms
1) Accepted small order,OEM,etc.
2) Ordinary delivery time: 3-7 days, according to order quantity.
3) Ready to shipping by sea ,DHL , Fedex, EMS, as soon as we receive payment
4) Accept T/T 100% advance. Western Union, PayPal.

5) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility

High Temperature Stability Fiber Optic Patch Cord With SC/UPC Connector Good Durability

High Temperature Stability Fiber Optic Patch Cord With SC/UPC Connector Good Durability
